WTZIRC3187 XTRweld 0.3% Zirconiated Tungsten Electrode, 3/16, Brown, 5 Piece
Tungsten is a rare metallic element used for manufacturing gas tungsten arc welding (GTAW) electrodes. The GTAW process relies on tungsten's hardness and high-temperature resistance to carry the welding current to the arc. Tungsten has the highest melting point of any metal, 3,410 degrees Celsius.
APPLICATIONS
- Zirconiated tungsten electrodes (AWS classification EWZr-1) contain a minimum of 99.10 percent tungsten and 0.15 to 0.40 percent zirconium. A zirconiated tungsten electrode produces an extremely stable arc and resists tungsten spitting. It is ideal for AC welding because it retains a balled tip and has a high resistance to contamination. Its current-carrying capability is equal to or greater than that of thoriated tungsten. Under no circumstances is zirconiated recommended for DC welding.
| Display Pack | 5 Piece |
| Welding Type | TIG (GTAW) |
| Diameter | 3/16 Inch |
| Length | 7 Inch |
| Material | Tungsten |
| Color | Brown |
| DC Current Range (-) Pure Tungsten | 380 to 600 A |
| DC Current Range (-) With Oxide | 480 to 650 A |
| DC Current Range (+) Pure Tungsten | 50 to 70 A |
| DC Current Range (+) With Oxide | 50 to 70 A |
| AC Current Range (Pure Tungsten) | 240 to 350 A |
| AC Current Range (With Oxide) | 330 to 4 A |
| Melting Point | 3410 °C |
| Approvals | EWZr-1 - ANSI/AWS A5.12, ISO6848 |
| Principle Oxide | ZrO2 |
| Mass Percent | 0.15 to 0.50% |
| Impurities Mass Percent | 0.5% Max |
| Country Origin | China |
