WTZIRC3125 XTRweld 0.3% Zirconiated Tungsten Electrode, 1/8, Brown, 10 Piece

(0)No Reviews yet
SKU: XTRWTZIRC3125

Tungsten is a rare metallic element used for manufacturing gas tungsten arc welding (GTAW) electrodes. The GTAW process relies on tungsten's hardness and high-temperature resistance to carry the welding current to the arc. Tungsten has the highest melting point of any metal, 3,410 degrees Celsius.

APPLICATIONS

    Zirconiated tungsten electrodes (AWS classification EWZr-1) contain a minimum of 99.10 percent tungsten and 0.15 to 0.40 percent zirconium. A zirconiated tungsten electrode produces an extremely stable arc and resists tungsten spitting. It is ideal for AC welding because it retains a balled tip and has a high resistance to contamination. Its current-carrying capability is equal to or greater than that of thoriated tungsten. Under no circumstances is zirconiated recommended for DC welding.
Display Pack10 Piece
Welding TypeTIG (GTAW)
Diameter1/8 Inch
Length7 Inch
MaterialTungsten
ColorBrown
DC Current Range (-) Pure Tungsten160 to 310 A
DC Current Range (-) With Oxide225 to 330 A
DC Current Range (+) Pure Tungsten20 to 35 A
DC Current Range (+) With Oxide20 to 35 A
AC Current Range (Pure Tungsten)150 to 190 A
AC Current Range (With Oxide)150 to 250 A
Melting Point3410 °C
ApprovalsEWZr-1 - ANSI/AWS A5.12, ISO6848
Principle OxideZrO2
Mass Percent0.15 to 0.50%
Impurities Mass Percent0.5% Max
Country OriginChina
