7000123456 3M™ 9500PC Double Coated Tape, Transparent, 1 1/2 Inch W, 36 yd L
3M™ Double Coated Tape 9500PC is a 5 mil (0.14 mm) 350 high performance acrylic adhesive double coat with a thin polyester carrier film on a 58#, 4.5 mil unprinted, polycoated kraft paper liner. The adhesive excels on low surface energy (LSE) substrates and at high temps.
KEY FEATURES
- Clear, 5 mil (0.14 mm) double coated tape with high performance acrylic
- 1.0 mil, clear PET carrier film for dimensional stability and ease of die cutting
- Adheres to powder coated surfaces, most plastics and difficult surfaces
- High-holding strength and short-term heat resistance up to 350°F (177°C)
- 58# unprinted polycoated kraft liner reduces edge burr during hard tool die cutting
| Color | Transparent |
| Width | 1 1/2 Inch |
| Length | 36 yd |
| Backing Material | Polyester Film |
| Face Side Adhesive Type | High Performance Acrylic |
| Back Side Adhesive Type | High Performance Acrylic |
| Thickness | 5.6 mil |
| Backing (Carrier) Thickness | 1 mil |
| Min. Temperature Rating | -40 °F |
| Max. Temperature Rating | 350 °F |
| Primary Liner | 62# Polycoated Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness | 4.5 mil |
| Total Tape Thickness without Liner | 5.6 mil |
| Carrier Thickness | 0.095 mil |
| Back Side Adhesive Thickness | 2.3 mil |
| Core Size | 3 Inch |
| Face Side Adhesive Thickness | 2.3 mil |
| Indoor/Outdoor | Both |
| Set Time | <10 Second |
