7000123453 3M™ 9576 Double Coated Tape, Transparent, 1 Inch W, 60 yd L, 4 mil
3M™ Double Coated Tape 9576 is a medium tack tape for general splicing and roll closing applications. This tape offers ultra-high peel strength and excellent shear strength for durability. It is conformable to irregular surfaces and offers excellent UV and heat resistance.
KEY FEATURES
- Medium tack double coated tape for roll-to-roll splicing, core starting and roll closing
- Excellent peel and shear strength to withstand rigorous splicing applications
- Bonds well to most substrates, including low surface energy plastics
- Excellent UV and heat resistance
- Conformable to irregular surfaces
- Double sided adhesion increases dimensional stability for easy handling
| Color | Transparent |
| Width | 1 Inch |
| Length | 60 yd |
| Backing Material | Polypropylene |
| Face Side Adhesive Type | High-Tack Acrylic |
| Back Side Adhesive Type | High-Tack Acrylic |
| Thickness | 4 mil |
| Backing (Carrier) Thickness | 1 mil |
| Min. Temperature Rating | -40 °F |
| Max. Temperature Rating | 165 °F |
| Primary Liner | 60# Densified Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness | 4 mil |
| Total Tape Thickness without Liner | 4 mil |
| Carrier Thickness | 1 mil |
| Back Side Adhesive Thickness | 1.5 mil |
| Face Side Adhesive Thickness | 1.5 mil |
| Application | Zero-Speed and General Splicing |
