7000049097 3M™ 9731 Double Coated Tape, Transparent, 1 Inch W, 36 yd L, 5.5 mil
3M™ Double Coated Tape 9731 was developed with a high-performance acrylic adhesive on the face side and a silicone adhesive on the liner side of a 1 mil clear PET carrier. It is excellent for demanding applications where silicone materials must be bonded to a range of substrates.
KEY FEATURES
- Ideal for attaching silicone rubber elastomers and foam
- Features acrylic and silicone adhesives for specialized applications such as silicone gasketing
- 3M™ Adhesive 350 on the face side provides exceptional temperature and chemical resistance
- 3 mil silicone adhesive on liner side bonds well to silicone substrates
- Double linered – Adhesive 350 on 58# 4.2 mil PCK liner and silicone adhesive on 3 mil PET liner
| Color | Transparent |
| Width | 1 Inch |
| Length | 36 yd |
| Backing Material | Polyester |
| Face Side Adhesive Type | High Performance Acrylic |
| Back Side Adhesive Type | Silicone |
| Thickness | 5.5 mil |
| Min. Temperature Rating | -40 °F |
| Max. Temperature Rating | 250 °F |
| Primary Liner | 58# Polycoated Kraft Paper |
| Primary Liner Color | Tan |
| Primary Liner Thickness | 4.2 mil |
| Secondary Liner | Polyester Film |
| Secondary Liner Color | Clear |
| Secondary Liner Thickness | 2.9 mil |
| Total Tape Thickness without Liner | 5.5 mil |
| Carrier Thickness | 0.095 mil |
| Back Side Adhesive Thickness | 2.9 mil |
| Face Side Adhesive Thickness | 1.6 mil |
| Indoor/Outdoor | Both |
| Set Time | <10 Second |
